Hose reel OSM 400

Our spring-retractable hose reels are specifically designed for professional and industrial use. High-quality components and a wide range of accessories allow them to be adapted to all work areas and applications. With their robust and precise construction, they offer a durable, reliable solution for a wide variety of requirements.

Additional features:
• Automatic spring retraction with a tension spring “Made in Germany”
• Hose lock to secure the hose with every rotation
• Fixed mounting bracket including a drilling template for easy installation
• Hose stopper as an end stop with inserts for various hose diameters
• TE hose with synthetic textile reinforcement, spiral made of steel and copper wire
Inner layer: NBR rubber, conductive
Outer layer: Synthetic neoprene rubber, ozone-, abrasion-, and oil-resistant
• High-quality swivel joint, 90° angled (see diameter for size)
• Swivel joint: 1/2“” female BSP stainless steel, Viton seal, max. 130°C (note max. hose temperature)
• Roller window adjustable to 3 positions
• Dimensions listed in the data sheet

For which applications is the 1TE hose suitable?
The 1TE hose is suitable for demanding applications in commerce and industry. It is designed for different media and versatile areas of application.

Which media can be conveyed with the 1TE hose?
The hose is suitable for the following media, among others:
• Water
• Compressed air
• Mineral oils
• biological oils
• Hydraulic oil
• Drilling emulsions
• Release agents or formwork oil

What material is the outer layer of the hose made of?
The outer layer is made of black rubber and is reinforced with a high-strength synthetic textile insert.

What properties does the outer layer have?
The outer layer of the 1TE hose is ozone, abrasion, and oil resistant, making it suitable for demanding industrial conditions.

For which temperature range is the hose designed?
The 1TE hose can be used in a temperature range from -20 °C to +90 °C.

Which standard does the 1TE hose comply with?
The hose complies with DIN 854 R6 (SAE 100).

Is the 1TE hose suitable for continuous industrial use?
Thanks to its robust design, high-strength textile reinforcement, and resistance to ozone, abrasion, and oil, the hose is particularly suitable for demanding applications in commerce and industry.
