Product illustration may differ in individual cases.

Hose reel OSM 500 Gas

Article no.: 1.500.701
954,00
incl. VAT plus 47,60  shipping
Delivery time 15-30 days
HS-Code: 73269050
Country of origin: IT

Technical data

  • Medium Gas
  • Diameter 8mm (5/16")
  • Casing Painted steel
  • Drive system Spring return
  • Length/Capacity 20m
  • Pressure 20bar

Description

Our spring-return hose reels are specially designed for professional and industrial use. High-quality components and a wide range of accessories enable adaptation to all work areas and applications. With a robust and precise design, they offer a durable, reliable solution for a wide range of requirements.

Further features:
Automatic spring retraction with tension spring "Made in Germany",
media guide especially for LPG, methane, propane, butane (other gases on request),
hose lock to secure the hose with each rotation, fixed mounting bracket including drilling template for easy assembly,
hose stopper as end stop with inserts for different hose diameters,
high-quality swivel joint angled 90° (size see diameter),
brass swivel joint, 2 connections 3/8"M BSP right + 3/8"M BSP left, Viton seal,
roller window adjustable in 3 positions,
dimensions listed in the data sheet

Illustration: New variant in RAL 7016 (anthracite) - as part of the color change, the old version in RAL 7035 (light gray) will still be delivered depending on stock.
