Product illustration may differ in individual cases.

Hose reel OSM 510

Article no.: 1.514.503
Product illustration may differ in individual cases.
1.517,00
incl. VAT plus 47,60  shipping
Delivery time 6-14 days
HS-Code: 73269050
Country of origin: IT
Shipping weight: 20.0 kg

Technical data

  • Medium Grease
  • Diameter 6mm (1/4")
  • Casing Stainless steel
  • Drive system Spring return
  • Length/Capacity 25m
  • Pressure 400bar

Description

Our hose reels with spring return are specially designed for professional and industrial use. High-quality components and a wide range of accessories enable adaptation to all work areas and applications. With robust and precise construction, they offer a long-lasting, reliable solution for a wide range of requirements.

Additional features:
Automatic spring return with tension spring "Made in Germany",
hose lock to fix the hose with every rotation,
swivel wall bracket with 110° swivel range including drilling template for easy installation,
hose stopper as end stop with inserts for different hose diameters,
high-quality swivel joint 90° angled (size see diameter),
swivel joint galvanized steel, 3/8" F BSP, polyurethane seal, max. 80°C (note max. hose temperature),
roller window adjustable in 3 positions,
dimensions listed in the data sheet
