Hose reel OSM 610

Article no.: 1.614.100
Product illustration may differ in individual cases.
1.047,00
incl. VAT plus 47,60  shipping
Delivery time 3-5 days
HS-Code: 73269050
Country of origin: IT
Shipping weight: 31.0 kg

Technical data

  • Medium Cold water, Compressed air, Diesel, Hot water, Vacuum
  • Diameter 15mm (5/8")
  • Casing Stainless steel
  • Drive system Spring return
  • Length/Capacity Ohne Schlauch
  • Pressure 20bar

Description

Our hose reels with spring return are specially designed for professional and industrial use. High-quality components and a wide range of accessories enable adaptation to all work areas and applications. With a robust and precise design, they offer a long-lasting, reliable solution for a wide range of requirements.

Additional features:
Automatic spring return with tension spring "Made in Germany",
hose lock to fix the hose in place with each rotation,
fixed mounting bracket including drilling template for easy assembly,
hose stopper as an end stop with inserts for different hose diameters,
high-quality swivel joint angled 90° (see diameter for size),
swivel joint galvanized steel, ½" F BSP, viton seal, max. 90°C (note max. temperature of hose)
roller window adjustable in 3 positions,
dimensions listed in the data sheet .
