Hose reel OSM 610 Duo

Article no.: 1.610.5000
Product illustration may differ in individual cases.

• Spring return & hose lock
• Painted steel casing
• Tension spring "Made in Germany"

935,00
incl. VAT plus 89,25  shipping
Delivery time 3-5 days
HS-Code: 73269050
EAN / GTIN: 4260554753074
Country of origin: IT
Shipping weight: 36.0 kg

Technical data

  • Medium Duo hose
  • Diameter 10mm (3/8")
  • Casing Painted steel
  • Drive system Spring return
  • Length/Capacity ohne Schlauch
  • Pressure 400bar

Description

Our hose reels with spring return are specially designed for professional and industrial use. High-quality components and a wide range of accessories enable adaptation to all work areas and applications. With a robust and precise design, they offer a long-lasting, reliable solution for a wide range of requirements.

Further features:
• automatic spring return with tension spring "Made in Germany",
• 2 media guides with connection on the right + left
• hose lock to fix the hose with every rotation,
• fixed mounting bracket including drilling template for easy assembly
• hose stopper as an end stop with inserts for different hose diameters
• galvanized steel swivel joint,
• 2 connections 3/8" F BSP, polyurethane seal, max. 80°C (note max. hose temperature)
• high-quality swivel joint angled 90° (see diameter for size)
• roller window adjustable in 3 positions

Illustration: New variant in RAL 7016 (anthracite) - as part of the color change, the old version in RAL 7035 (light gray) will still be delivered depending on stock levels.
