Our spring-retractable hose reels are specifically designed for professional and industrial use. High-quality components and a wide range of accessories allow them to be adapted to all work areas and applications. With their robust and precise construction, they offer a durable, reliable solution for a wide variety of requirements.
Additional features:
• Automatic spring-return mechanism with a tension spring “Made in Germany”
• Hose lock to secure the hose with every rotation
• Swivel wall mount with a 110° swivel range, including a drilling template for easy installation
• Hose stopper as an end stop with inserts for various hose diameters
• TE hose with synthetic textile reinforcement, spiral made of steel and copper wire
Inner layer: NBR rubber, conductive
Outer layer: Synthetic neoprene rubber, ozone-, abrasion-, and oil-resistant
• High-quality swivel joint, 90° angled (see diameter for size)
• Swivel joint: 1" female BSP stainless steel, Viton seal, max. 130°C (note max. hose temperature)
• Roller window adjustable to 3 positions
• Dimensions listed in the data sheet
